RF Design Services

RF Circuit Design

Industrial, military, and consumer product circuit design.

From custom protocol transmitters and receivers for communications and radar to today's wireless enabled consumer products, our RF engineers deliver designs to meet your cost, range, sensitivity, and spurious emissions requirements. We offer complete circuit and firmware design for RF products including RF, digital, and power supply sections.

Our designs are found in numerous consumer products (30,000+ unit production) as well as in smaller scale specialized products for government, military, and research applications. Recent product & design work includes:

• IoT products
• Wearable Technology
• Instrumentation
• Wireless Sensors
• Radar
• Aeronautical Communications
• CATV
• Antenna Matches
• Free Space Optical
• Radio Over Fiber

Close

Board Layout

Printed circuit board layout.

We provide complete printed circuit board layout services. Our capabilities include multi-layer boards and buried vias. Our engineers use the KiCad electronic design automation suite, developed at IUT Grenoble and CERN. Unlike a typical layout service, we are extra mindful of RF engineering requirements, electromagnetic compatibility, transmission line impedance, and all aspects of layout which can impact the RF performance of your design. We typically deliver your project with industry-standard Gerber and drill files. We typically work closely with a board house and assembly house to ensure high quality production.

Close

Test & Measurement

RF, Microwave, and Photonics Lab.

Our RF engineers work in a fully equipped radio frequency design lab with tools for design, prototyping, evaluating, and testing. The short list of key tools and lab equipment follows.

• HP Vector Network Analyzer
• Agilent Vector Signal Generator
• HP Spectrum Analyzers (2)
• ILX Lightwave Fiberoptic Test w/1550nm DFB lasers (10)
• Tektronix Oscilloscopes - Digital & Analog (2)
• Distortion Analyzer
• Power Meters (RF/optical)
• LR Tech Thermal Test Oven
• DC Power Supplies (4)
• High Power RF loads (2)
• Bird & HP Power meters (2)
• Weller & Metcal solder rework stations
• Amscope microscope

Close

Broadcast Engineering

FM and Internet radio.

We offer a range of broadcast engineering consulting services for terrestrial and Internet radio. Our services cover the air chain from studio to transmitter. New-media services include Internet broadcast setup, software, automation, and website integration.

Our AudioRack Suite is one of the most flexible, and reliable radio automation and live-assist packages available for OS X (soon to be available for Linux). We provide custom installation, interactive web-site/streaming integration, configuration, and operator training for this powerful open-source package. A key features includes our custom streaming protocol, featuring forward error correction and interleaving for unparalleled Internet studio-to-transmitter link (STL) reliability.

Our RF engineers co-own and currently operate the studio and transmitter facility for 95.5 FM KRKQ, Telluride, CO, branded as Mountain Chill®

• Audio Rack Version 4
• Resilient Streaming Protocol
• KRKQ - Mountain Chill®

Close

Microwave Photonics

Radio Over Fiber.

Fiber-optics offer an advantageous low-loss means of delivering signals from HF to ELF between a basestation/head-end and remote locations for applications such as CATV, WiFi, LTE, and radar [1]. Radio Over Fiber (aka RF Photonics) is also the best means of generating true-time delay for ultra-wideband signal processing and dynamic beamsteering.

In 2008, Red Mountain Radio pioneered a new application of Radio Over Fiber [2], enabling radar in the deep, high temperature downhole environment.

• [1] Funk et. al. - Microwave Photonics - Ch 6.
• [2] Funk et. al, US Patent #7450532B

Close

Wireless Enabled Devices

Internet of things (IoT), machine-to-machine (M2M), wearables, BT/Wifi/GPS enabled devices, and beyond...

Today's wireless enabled devices take RF engineering and RF design to demanding levels, requiring high performance with very low per-unit costs in increasingly smaller packages.

Our designs address RF issues that remain critical to market success, especially with today's wireless chipsets and modules; antenna size and matching, spurious emissions, radiofrequency interference, battery lifetime, and standards compliance including PTCRB.

Often, our clients opt for a complete circuit design with an embedded microrocessor, firmware (C, etc.), power supply, charger, and interface circuitry. We are happy to support clients throughout the process from initial design requirements through third-party certification and assembly/production.

Standards that we design to include

• LTE, 3G
• BT/BTLE
• WiFi
• GPS
• NFC

Close
